Aleo
Art-Nr. 6357858
LEO-N SOL S82 370W Solrif
CHF 437.50
ALEO SOLAR Solrif Topcon-Modul schwarz
Hersteller Artikelnummer: S82T370.0.5W
Hersteller Artikelnummer: S82T370.0.5W
Verfügbarkeit:
Auf Lager
SKU
6357858
Product information
- Cable included (approx. 120 cm) and MC4 EVO connection system
- Solrif frame in black anodized aluminum Solrif N
- high-performance Topcon solar cells
- Version with 10 busbars
- Glass thickness: 3.2 mm
- hail resistance: RG 3 ( AEAI Certificate )
Can be used in the same string with the following modules:
- 6357859, aleo Solar Leo-N Sol S84 420WSolrif
| Brands | Aleo |
|---|
| Module reaction to fire: | C, IEC 61730 |
| Maximum surface load capacity (pressure) (Pa): | 5400 |
| Max. pressure Wind load (suction) (Pa): | 2400 |
| Number of cells: | 96 |
| Bifacial: | No |
| Bus bars (p.): | 10 |
| Color of the back sheet on the cell side: | black |
| Protection class: | IP68 |
| Front glass thickness (mm): | 3.20 |
| Hail resistance class: | HW 3 |
| Built-in optimizer: | No |
| Minus cable length (cm): | 120.00 |
| Cable length (cm) plus: | 120.00 |
| Short circuit current (A): | 13.13 |
| Open circuit voltage Uoc (V): | 34.71 |
| Power tolerance: | +4.99 |
| Maximum reverse current (A): | 25 |
| Max. system voltage (V): | 1000 |
| Module composition: | glass film |
| Module efficiency (%): | 19.70 |
| Nominal power (Wc): | 370 |
| Nominal voltage Umpp (V): | 29.67 |
| Nominal current Impp (A): | 12.47 |
| Frame color: | black |
| Frame type: | roof integration frame |
| Connector Type: | MC4 |
| Temperature coefficient Isc (%/C): | 0.0290 |
| Temperature coefficient Pmpp (%/C): | -0.3100 |
| Temperature coefficient Uoc (%/C): | -0.2400 |
| Cell section: | half-cell |
| Cell type: | monocrystalline |
| Manufacturer: | aleo |
| Manufacturer item designation: | LEO-N SOL S82 370W |
| Manufacturer's item number: | S82T370.0.5W |
| Instrastat product number (HS-Code): | 85414300 |
| Brand: | aleo |
| Country of origin: | Germany |
| Certificate 1: | IEC/TÜV |
| Certificate 2: | Class 2 Protection |
| Manufacturer's Product Name: : | LEO-N SOL S82 370W Solrif |
| Number of pallets per container: | 26 |
| Number per container: | 598 |
| Quantity per pallet: | 23 |
| Pallet weight (kg): | 492.00 |
| Width without packaging (mm): | 1,607.00 |
| Weight without packaging (kg): | 20,500 |
| Height without packaging (mm): | 17.00 |
| Length without packaging (mm): | 1,169.00 |
| Guarantor: | aleo |
| Performance Warranty (years): | 30 |
| Linear degressivity in %: | 0.4 |
| Product Warranty (years): | 30 |
| Initial % for the linear guarantee: | 99 |
